Tech Specs
| Type | 2-Way passive monitor | |
| Enclosure Design | Wedged cabinet – bass reflex | |
| Power Output (RMS) | 410W (RMS) 560W (Program) 1100W (Peak) |
|
| Frequency Range | 50Hz – 19kHz | |
| Nominal Impedance | 8Ohm | |
| Crossover Frequency | 2000Hz | |
| Transducer Type | 15″ MF (2.5in VC) EU transducer 1″ HF (1.73in VC) EU transducer |
|
| Dispersion | CD horn, 90°x60° and 60°x90° User-rotatable |
|
| Connector | 2x NL4, parallel-connected | |
| Max. SPL (peak) | 127dB @ 1m | |
| Construction | 15mm birch plywood, textured polyurea coating | |
| Grille | Custom perforated metal grille with acoustic foam | |
| Installation / Rigging / Flying | 4 rubber feet Side handles, 4x M8 inserts + 2x M10 inserts Prepared to fit a “U” bracket |
|
| Dimensions (WxDxH) | 730x485x360mm 28.73×19.09×14.17in |
|
| Weight | 25Kg 55.16lb |
